APPENDIX A
DL.2 and Axon DMX Protocol
DL2 Digital Light User Manual 241
27 6
Global
Effect 2
Pan and Scale. Mod1 = horizontal position,
Mod2 = vertical position, Mod3 = Zoom
255 100 0 0
28 7
Global Effect 2
Modifier 1
These Modifier parameters adjust the option
selected in Channel 27 for DL.2 fixtures or
Channel 3 for Axon Media Servers.
The type of adjustment and the default value
depends on the particular effect.
For more about Modifier functionality, see
Global
Effect Mode 1 and Effect Mode 2 on page
108, and specific effect options listed
alphabetically in Chapter 13.
0-255 0-100
NA NA
29 8
Global Effect 2
Modifier 2
0-255 0-100
30 9
Global Effect 2
Modifier 3
0-255 0-100
Channel #
Function Description
Value Default
DL.2 Axon dec. % dec. %
