4-6

Chapter 4

Troubleshooting Guide

Troubleshooting

3. If the workstation does not display the SCSI devices under the Fibre

Channel HBA in the control panel, restart the workstation and then
recheck for the appearance of the library SCSI devices.

4. (If DLT) Run the tape diagnostic utility from the NT workstation to

verify that the library and drives are detected and pass all self-tests.

NOTE

(If DLT) If the tape diagnostic utility has not been installed, install this
software from the DIAG subdirectory on the User Guide CD-ROM.

5. Verify SCSI Bus Configuration: Check all appropriate devices for the

following conditions:

• Termination: Problems with termination can cause intermittent or

hard failure. Two connectors are implemented for each SCSI bus,
supporting middle of bus configurations.

Terminate the SCSI bus on both ends, and only at the ends of the
bus. Check each terminator and connector for bent pins.

• Bus Type: Single-ended devices cannot be combined with

differential devices on the same bus. Similarly, differential
terminators cannot be used on the single-ended Fibre Bridge.

• Device ID: Each device on a SCSI bus must have a unique ID. The

default SCSI ID of the Fibre Bridge is 7. Make sure that this ID is
not in use on the bus. Check the library user guide for the default
SCSI IDs. Verify that other IDs on the bus are not in conflict.

• Cabling: Check SCSI cables to verify that they are functional, then

perform the following procedures:

a. Be sure the maximum cable length on the single-ended SCSI

cable connected to the Fibre Bridge does not exceed a total of 3
meters.

b. Check all cable connections and pins on the connectors. Reseat

the connections if necessary.
