HC900 Hybrid Controller Communications User Guide
87
12/07
Fixed
Address
(hex)
Fixed
Register
(decimal)
Parameter Name
Access Notes
6706 26375 Output
Status
#9-12 R
Bit
Packed:
Bit 0: Output #9 Enable: 0=NO, 1=YES
Bit 1: Output #9 Used: 0=NO, 1=YES
Bit 2: Output #9 ON: 0=OFF, 1=ON
Bit 3: Unused
Bit 4: Output #10 Enable: 0=NO, 1=YES
Bit 5: Output #10 Used: 0=NO, 1=YES
Bit 6: Output #10 ON: 0=OFF, 1=ON
Bit 7: Unused
Bit 8: Output #11 Enable: 0=NO, 1=YES
Bit 9: Output # Used: 0=NO, 1=YES
Bit 10: Output #11 ON: 0=OFF, 1=ON
Bit 11: Unused
Bit 12: Output #12 Enable: 0=NO, 1=YES
Bit 13: Output #12 Used: 0=NO, 1=YES
Bit 14: Output #12 ON: 0=OFF, 1=ON
Bit 15: Unused
6707 26376 Output
Status
#13-16
R Bit
Packed:
Bit 0: Output #13 Enable: 0=NO, 1=YES
Bit 1: Output #13 Used: 0=NO, 1=YES
Bit 2: Output #13 ON: 0=OFF, 1=ON
Bit 3: Unused
Bit 4: Output # Enable: 0=NO, 1=YES
Bit 5: Output #14 Used: 0=NO, 1=YES
Bit 6: Output #14 ON: 0=OFF, 1=ON
Bit 7: Unused
Bit 8: Output #15 Enable: 0=NO, 1=YES
Bit 9: Output #15 Used: 0=NO, 1=YES
Bit 10: Output #15 ON: 0=OFF, 1=ON
Bit 11: Unused
Bit 12: Output #16 Enable: 0=NO, 1=YES
Bit 13: Output #16 Used: 0=NO, 1=YES
Bit 14: Output #16 ON: 0=OFF, 1=ON
Bit 15: Unused
6708
26377
Request Style
R
Bit Packed:
Bit 0: Direct: 0=NO, 1=YES
Bit 1: Rotary: 0=NO, 1=YES
Bit 2: FOFO: 0=NO, 1=YES
Bit 3: Fixed: 0=NO, 1=YES
Bit 4-15: Unused
6709
26378
Direct Request
W
Unsigned 16 Integer
Data Ignored
670A
26379
Rotary Request
W
Unsigned 16 Integer
Data Ignored
670B
26380
First on/First off
Request
W
Unsigned 16 Integer
Data Ignored
670C
26381
Fixed Request
W
Unsigned 16 Integer
Data Ignored
