60 HC900 Hybrid Controller Communications User Guide Revision 10
12/07
Fixed
Address
(hex) Fixed
Register
(decimal) Parameter Access Notes
1E0F 7696 Reset* W Signed 16 bit integer
Write to location Resets Profile after
program is first in Hold mode;
Data ignored
Setpoint Programmer Additional Parameters:
1F00 7937 Current Program Number* R/W Floating Point
Indicates the present profile number in use.
This also allows entry of a profile number
from the HC900 stored profile memory (if
profiles have been stored in the controller)
and will retrieve the profile data for a display
showing a SP profile segment table.
Typically, when recipes are downloaded from
third party software, this will be the number
generated by the Program Save Request
parameter
A write to this register loads the program into
the set point programmer function block; if 0
is written, the function block’s program is
cleared.
1F02 7939 Program Save Request** R/W Floating Point
Assigns profile parameters downloaded to a
profile number such as 1. This is required by
the HC900 to be the last parameter
downloaded. This overwrites what is in this
HC900 SP Profile memory location on each
download of a new SP profile.
Saves the program into the archive. Writing
to this register is prohibited in the run mode.
1F04 7941 Auxiliary Output* R Floating Point
1F06 7943 Guaranteed Soak Low** R/W Floating Point
Presets High Deviation setting in engineering
units.
Writing to this register is only permissible in
the reset or ready mode
1F08 7945 Guaranteed Soak High** R/W Floating Point
Presets Low Deviation setting in engineering
units.
Writing to this register is only permissible in
the reset or ready mode
1F0A 7947 Restart Ramp Rate R/W Floating Point
Writing to this register is only permissible in
the reset or ready mode
1F0C 7949 Display High Range Limit R/W Floating Point
Writing to this register is only permissible in
the reset or ready mode. Not presently used
in the HC900 but can be used on external
operator interfaces.
1F0E 7951 Display Low Range Limit R/W Floating Point
Writing to this register is only permissible in
the reset or ready mode. Not presently used
in the HC900 but can be used on external
operator interfaces
