Revision 10 HC900 Hybrid Controller Communications User Guide 71
12/07
Segment registers
The table below describes the registers that are part of a setpoint schedule. A schedule contains 50
segments. Each segment is made up of 28 parameters (Segment n Guaranteed Soak Type 1 through
Segment n Recycle Segment) which consumes 48 (30 hex) registers, for a total of 2400 contiguous
registers. This table contains fixed addresses of Schedule #1 Segments; see Table 6-1 for fixed addresses
of Schedule Segments. In a custom map the segment registers contiguously follow the other Schedule
registers listed in Table 6-15.
All 50 segments are used to define a schedule. You can’t specify which segments get assigned.
The addresses given in Table 6-17 do not necessarily apply to segments in the custom map. For custom
addresses view or print a report in HC Designer.
Table 6-17 Schedule Segments 1-50
Fixed
Start
Address
(Hex) Fixed
Start
Register
(Decimal) Offset
(Hex) Offset
(Decimal) Parameter Name Access Notes
3200 12801 0000 0000 Segment #1 Guaranteed Soak
Type 1
(Bit Packed)
R/W Bit Packed
Bit 0: Off
Bit 1: Low
Bit 2: High
Bit 3: Low & High
Bit 4…15: Unused
Note 1
3201 12802 0001 0001 Segment #1 Guaranteed Soak
Type 2
R/W See Guaranteed Soak Type 1
3202 12803 0002 0002 Segment #1 Guaranteed Soak
Type 3
R/W See Guaranteed Soak Type 1
3203 12804 0003 0003 Segment #1 Guaranteed Soak
Type 4
R/W See Guaranteed Soak Type 1
3204 12805 0004 0004 Segment #1 Guaranteed Soak
Type 5
R/W See Guaranteed Soak Type 1
3205 12806 0005 0005 Segment #1 Guaranteed Soak
Type 6
R/W See Guaranteed Soak Type 1
3206 12807 0006 0006 Segment #1 Guaranteed Soak
Type 7
R/W See Guaranteed Soak Type 1
3207 12808 0007 0007 Segment #1 Guaranteed Soak
Type 8
R/W See Guaranteed Soak Type 1
3208 12809 0008 0008 Segment #1 Events R/W Bit Packed
Bit 0: Event #1
: :
Bit 15: Event #15
0: Event OFF
1: Event ON
Note 2
320A 12811 000A 0010 Segment #1 Time R/W Floating Point in seconds Note
1
320C 12813 000C 0012 Segment #1 Output #1 Ramp or
Soak value R/W Floating Point Note 1
320E 12815 000E 0014 Segment #1 Output #2 Ramp or
Soak value R/W Floating Point Note 1
3210 12817 0010 0016 Segment #1 Output #3 Ramp or
Soak value R/W Floating Point Note 1
