86 HC900 Hybrid Controller Communications User Guide Revision 10
12/07
Fixed
Address
(hex) Fixed
Register
(decimal) Parameter Name Access Notes
6704 26373 Output Status #1-4 R Bit Packed:
Bit 0: Output #1 Enable: 0=NO, 1=YES
Bit 1: Output #1 Used: 0=NO, 1=YES
Bit 2: Output #1 ON: 0=OFF, 1=ON
Bit 3: Unused
Bit 4: Output #2 Enable: 0=NO, 1=YES
Bit 5: Output #2 Used: 0=NO, 1=YES
Bit 6: Output #2 ON: 0=OFF, 1=ON
Bit 7: Unused
Bit 8: Output #3 Enable: 0=NO, 1=YES
Bit 9: Output #3 Used: 0=NO, 1=YES
Bit 10: Output #3 ON: 0=OFF, 1=ON
Bit 11: Unused
Bit 12: Output #4 Enable: 0=NO, 1=YES
Bit 13: Output #4 Used: 0=NO, 1=YES
Bit 14: Output #4 ON: 0=OFF, 1=ON
Bit 15: Unused
6705 26374 Output Status #5-8 R Bit Packed:
Bit 0: Output #5 Enable: 0=NO, 1=YES
Bit 1: Output #5 Used: 0=NO, 1=YES
Bit 2: Output #5 ON: 0=OFF, 1=ON
Bit 3: Unused
Bit 4: Output #6 Enable: 0=NO, 1=YES
Bit 5: Output #6 Used: 0=NO, 1=YES
Bit 6: Output #6 ON: 0=OFF, 1=ON
Bit 7: Unused
Bit 8: Output #7 Enable: 0=NO, 1=YES
Bit 9: Output #7 Used: 0=NO, 1=YES
Bit 10: Output # ON: 0=OFF, 1=ON
Bit 11: Unused
Bit 12: Output #8 Enable: 0=NO, 1=YES
Bit 13: Output #8 Used: 0=NO, 1=YES
Bit 14: Output # ON: 0=OFF, 1=ON
Bit 15: Unused
