72 HC900 Hybrid Controller Communications User Guide Revision 10
12/07
Fixed
Start
Address
(Hex) Fixed
Start
Register
(Decimal) Offset
(Hex) Offset
(Decimal) Parameter Name Access Notes
3212 12819 0012 0018 Segment #1 Output #4 Ramp or
Soak value R/W Floating Point Note 1
3214 12821 0014 0020 Segment #1 Output #5 Ramp or
Soak value R/W Floating Point Note 1
3216 12823 0016 0022 Segment #1 Output #6 Ramp or
Soak value R/W Floating Point Note 1
3218 12825 0018 0024 Segment #1 Output #7 Ramp or
Soak value R/W Floating Point Note 1
321A 12827 001A 0026 Segment #1 Output #8 Ramp or
Soak value R/W Floating Point Note 1
321C 12829 001C 0028 Segment #1 Soak value for
Auxiliary Output #1 R/W Floating Point Note 1
321E 12831 001E 0030 Segment #1 Soak value for
Auxiliary Output #2 R/W Floating Point Note 1
3220 12833 0020 0032 Segment #1 Soak value for
Auxiliary Output #3 R/W Floating Point Note 1
3222 12835 0022 0034 Segment #1 Soak value for
Auxiliary Output #4 R/W Floating Point Note 1
3224 12837 0024 0036 Segment #1 Soak value for
Auxiliary Output #5 R/W Floating Point Note 1
3226 12839 0026 0038 Segment #1 Soak value for
Auxiliary Output #6 R/W Floating Point Note 1
3228 12841 0028 0040 Segment #1 Soak value for
Auxiliary Output #7 R/W Floating Point Note 1
322A 12843 002A 0042 Segment #1 Soak value for
Auxiliary Output #8 R/W Floating Point Note 1
322C 12845 002C 0044 Segment #1 Recycle R/W Number of times to recycle
Floating Point Note 2
322E 12847 002E 0046 Segment #1 Recycle Segment R/W Floating Point Note 2
The above parameters are repeated for segments 2 through 50.
3230 12848 0030 0048 Segment #2 Guaranteed Soak
Type 1
(Bit Packed)
R/W Bit Packed
Bit 0: Off
Bit 1: Low
Bit 2: High
Bit 3: Low & High
Bit 4…15: Unused
Note 1
.
.
. .
.
. .
.
. .
.
. .
.
. .
.
. .
.
.
3B5E 15199 095E 2398 Segment #50 Recycle Segment R/W Floating Point Note 2
Note 1: Writing to this register is not permissible in the run mode.
Note 2: Writing to this register is only permissible in reset or ready mode
