Table 6-28 custom map loop parameters – Honeywell HC900 User Manual
Page 100
92
HC900 Hybrid Controller Communications User Guide
Revision 10
12/07
Table 6-28 Custom map Loop parameters
Parameter Name
Loop type
Notes
PID On/
Off
Carb 3Pos AMB
Access
Accutune III Selection
9
9
R/W
Integer:
0 – disable
1 – limit cycle
2 – SP tuning
SP Change Steps
9
9
R/W
Float in the range of 5% to 15%
SP Step Direction
9
9
Integer:
0 = UP
1 = DOWN
PV Adabtive
Enable/Disable
9
9
R/W
Integer:
0 = Disable
1 = Enable
Autotune Error
9
9
R/W
0=Tune Not Ready or in Wait State
1=Tune Ready
2=Tune Running
3=Failed Process Identification – SP Tune
4=SP Error – SP Tune
5=Bad Kpg – SP Tune
6=Failed Output Limit – SP Tune
7=Failed Minimum PV – SP Tune
8=PV Adaptive Running
9=Tuning Aborted
AutoManual
LocalRemote Mode
9 9 9
9
9
R/W
R/W
R/W
R
R
R/W
Unsigned 16
0.0 = LSP MAN
1.0 = LSP AUTO
2.0 = RSP AUTO
4.0 = LSP IMAN or RSP IMAN
5.0 = LSP LO or RSP LO
6.0 = RSP_MAN
Table 6-29 Custom map Push Button and Four Selector Switch parameters
Parameter Name
Access
Notes
Button F1
W
Integer: Write 1 to “push” the button
Button F2
W
Integer: Write 1 to “push” the button
Button F3
W
Integer: Write 1 to “push” the button
Button F4
W
Integer: Write 1 to “push” the button
Bank A State
R/W
Integer in the range of 1 to 4
Bank B State
R/W
Integer in the range of 1 to 4
Bank C State
R/W
Integer in the range of 1 to 4
Bank D State
R/W
Integer in the range of 1 to 4
