Page 8
8
Back
H
SYSTEM SELECT switch
Used for selecting the video format of the signal to
be output from the HDMI OUT, MONITOR OUT,
and LINE OUT terminals.
For details, see “SYSTEM SELECT switch
settings” (page 63).
I
AC adapter cord clamper
Fix the cord of an AC adapter with the cord clamper
so that it does not come out.
J
IR SELECT switch
Select the camera number when you operate
multiple cameras with the same remote commander.
K
Remote commander sensors
These are sensors for the supplied remote
commander.
L
Network reset switch
This switch is for initializing network settings such
as the IP address.
Press the switch for 5 seconds or longer with a pen
point, etc., to initialize the network settings.
The camera will reboot, and the network settings
will return to the factory default.
Factory settings for network
IP address: 192.168.0.100
Subnet mask: 255.255.255.0
Default gateway: 0.0.0.0
Name: CAM1
User name: admin
*
Password: Admin_1234
* The user name cannot be changed.
M
CAMERA SETUP switches
SDI format/level settings
The baud rate settings and camera address settings
of RS-422 are set for VISCA communication.
CAMERA SETUP switch settings
1
SDI format/level settings
This setting is enabled when the signal format is
1920×1080/50p or 1920×1080/59.94p.
* Turn the power off or to standby, then turn the power
on to reflect the changes after setting.
4
Baud Rate settings of RS-422 for VISCA
communication
* Turn the power off and on to reflect the changes
after setting.
567
Camera address settings
Sets camera address.
EXT
S
YNC IN
TERMI-
NATION
ON OFF
ON
ON
OFF
LINE OUT
S
DI 1
O
S
D
LAN
S
DI 2
2 3 4 5 6 7 8
1
MONITOR OUT
HDMI OUT
S
DI 1
S
DI 2
IN
S
Y
S
TEM
S
ELECT
IR
S
ELECT
CAMERA
S
ETUP
1 2 3
VI
S
CA R
S
- 422 OUT
12V
qd
qf
qg
qh
qj
w;
wa
ws
wd
wf
ql
qk
9
8
0
qa
qs
EXT
S
YNC IN
TERMI-
NATION
ON OFF
ON
ON
OFF
O
S
D
LAN
2 3 4 5 6 7 8
1
HDMI OUT
IN
S
Y
S
TEM
S
ELECT
IR
S
ELECT
CAMERA
S
ETUP
1 2 3
VI
S
CA R
S
- 422 OUT
12V
MONITOR
OUT
LINE OUT
qd
qf
qg
qh
qj
w;
wa
ws
wd
wf
ql
qk
9
8
0
qa
qs
BRC-X1000
BRC-H800
Switch No.
Setting items
1
Setting up
3
G-SDI level
2
System reserve
3
4
Baud Rate settings of RS-422 for VISCA
communication
5
VISCA Address settings for VISCA
communication
6
7
8
System reserve
Switch state
SDI format/level
ON
Level-B
OFF
Level-A
Switch state
Baud Rate
ON
38
400 bps
OFF
9600 bps
1
4 5 6 7
