22
7
Secure the ceiling brackets (A) and (B)
using supplied three screws (
3 M3×8).
8
Connect the cables to the terminals at the
back of the camera.
• Make sure no load is applied to the connectors of
the cables.
• For measures that prevent the cord of the AC
adapter (not supplied) or HDMI cable from being
pulled out, see “Connecting the Camera”
(page 23).
• For measures that prevent the HDMI cable from
being pulled out, follow the steps in “9-2” of
“Installing the camera on the ceiling (example)”
after connecting the HDMI cable. Then, connect
all the other cables.
How to remove the camera
1
Remove the three screws which secured the
camera in Step 7 of “Installing the camera
on a shelf located at a high spot (example)”.
2
Turn the camera unit counterclockwise to
remove it.
3 M 3 × 8
(supplied)
Notes
