15
Installation and Connection
Installing the Camera
• Be sure to provide safety measures against falling
when you mount the camera.
• Do not grasp the camera head when carrying the
camera.
• Do not turn the camera head by hand. Doing so may
result in a camera malfunction.
Installing the camera on a desk
Installing the camera on a desk
Place the camera on a flat surface.
If you have to place the camera on an inclined surface,
make sure that the inclination is less than ±15 degrees to
guarantee pan/tilt performance, and take measures to
prevent it from falling.
Attaching the camera to a tripod
Screw the tripod screw into a tripod screw hole on the
bottom of the camera.
The tripod should be placed on a level surface, and
tighten the screw firmly by hand.
The tripod screw should be compliant with the following
standards.
4 = 4.5 mm to 7 mm
4 = 0.18 to 0.27 inches
Notes
Caution
Installation of the camera using the tripod screws and
screw holes should not be done for installation on a
ceiling, shelf, or other high spot.
1 / 4 -20UNC
