28

Externally synchronizing a single
camera

External synchronization

Multiple cameras can be synchronized to a specific
reference signal.
Providing a reference signal to the EXT SYNC IN
terminal (page 9) allows the camera to be synchronized
in phase with the video signal. Depending on the system
frequency, the compatible reference signal varies.

• When the reference signal is unstable, the camera

cannot be externally synchronized.

• Sub-carriers cannot be synchronized.

System select

Compatible reference signals

0:

38

40×2160/29.97p

1: 1920×10

8

0/59.94p

2: 1920×10

8

0/59.94i

1920×10

8

0/59.94i

720×4

8

6/59.94i (NTSC)

4,7: 12

8

0×720/59.94p

1920×10

8

0/59.94i

12

8

0×720/59.94p

720×4

8

6/59.94i (NTSC)

8

:

38

40×2160/25p

9: 1920×10

8

0/50p

A:1920×10

8

0/50i

1920×10

8

0/50i

720×576/50i (PAL)

C:12

8

0×720/50p

1920×10

8

0/50i

12

8

0×720/50p

720×576/50i (PAL)

E:

38

40×2160/2

3

.9

8

p

F: 1920×10

8

0/2

3

.9

8

p

1920×10

8

0/47.95i (2

3

.9

8

PsF)

Notes

EXT SYNC IN

TERMI-
NATION

ON OFF

ON

ON

OFF

LINE OUT

SDI 1

OSD

LAN

SDI 2

2

3

4 5 6 7

8

1

MONITOR OUT

HDMI OUT

SDI 1

SDI 2

IN

SYSTEM
SELECT

IR SELECT

CAMERA SETUP

1 2

3

VISCA RS - 422 OUT

12V

Connecting cable with
BNC connector
(commercially available)

To SYNC OUT terminal

Synchronizing signal generator

TERMINATION
switch: On
