55
Menu Configuration
The camera menu is configured as described below. For more details, refer to the pages in parentheses.
The initial settings of each item are in bold. Only supported functions are displayed.
EXPOSURE MODE FULL AUTO , MANUAL, SHUTTER Pri, IRIS Pri, GAIN Pri
GAIN –3dB, 0dB , 3dB, 6dB, 9dB, 12dB, 15dB, 18dB, 21dB, 24dB, 27dB, 30dB, 33dB
(Adjustable only when MODE in the EXPOSURE menu is set to MANUAL or GAIN Pri.)
GAIN LIMIT 9dB, 12dB, 15dB, 18dB, 21dB, 24dB, OFF
(Adjustable only when MODE in the EXPOSURE menu is set to FULL AUTO,
SHUTTER Pri or IRIS Pri.)
POINT POSITION 0dB , 3dB, 6dB, 9dB, 12dB, 15dB, 18dB, 21dB, 24dB
(Adjustable only when MODE in the EXPOSURE menu is set to FULL AUTO or IRIS Pri.)
SPEED For the 59.94 frame rate of video output: 1/8, 1/15, 1/30, 1/50, 1/60 , 1/90, 1/100, 1/125,
1/180, 1/250, 1/350, 1/500, 1/725, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/6000, 1/10000
For the 29.97 frame rate of video output: 1/8, 1/15,
1/ 3 0 , 1/50, 1/60, 1/90, 1/100, 1/125,
1/180, 1/250, 1/350, 1/500, 1/725, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/6000, 1/10000
For the 50 frame rate of video output: 1/6, 1/12, 1/25, 1/30,
1/50 , 1/60, 1/100, 1/120, 1/150,
1/215, 1/300, 1/425, 1/600, 1/1000, 1/1250, 1/1750, 1/2500, 1/3500, 1/6000, 1/10000
For the 25 frame rate of video output: 1/6, 1/12,
1/25 , 1/30, 1/50, 1/60, 1/100, 1/120, 1/150,
1/215, 1/300, 1/425, 1/600, 1/1000, 1/1250, 1/1750, 1/2500, 1/3500, 1/6000, 1/10000
For the 23.98 frame rate of video output: 1/6, 1/12, 1/24, 1/25, 1/40,
1/4 8 , 1/50, 1/60, 1/96, 1/100,
1/120, 1/144, 1/192, 1/200, 1/288, 1/400, 1/576, 1/1200, 1/2400, 1/4800, 1/10000
(Adjustable only when MODE in the EXPOSURE menu is set to MANUAL or SHUTTER Pri.)
MAX SPEED For the 59.94 frame rate of video output: 1/30, 1/50, 1/60, 1/90, 1/100, 1/125, 1/180, 1/250,
1/350, 1/500, 1/725, 1/1000, 1/1500,
1/2000 , 1/3000, 1/4000, 1/6000, 1/10000
For the 29.97 frame rate of video output: 1/30, 1/50, 1/60, 1/90, 1/100, 1/125, 1/180, 1/250,
1/350, 1/500, 1/725, 1/1000, 1/1500,
1/2000 , 1/3000, 1/4000, 1/6000, 1/10000
For the 50 frame rate of video output: 1/25, 1/30, 1/50, 1/60, 1/100, 1/120, 1/150, 1/215, 1/300,
1/425, 1/600, 1/1000, 1/1250,
1/1750 , 1/2500, 1/3500, 1/6000, 1/10000
For the 25 frame rate of video output: 1/25, 1/30, 1/50, 1/60, 1/100, 1/120, 1/150, 1/215, 1/300,
1/425, 1/600, 1/1000, 1/1250,
1/1750 , 1/2500, 1/3500, 1/6000, 1/10000
For the 23.98 frame rate of video output: 1/24, 1/25, 1/40, 1/48, 1/50, 1/60, 1/96, 1/100, 1/120, 1/144,
1/192, 1/200, 1/288, 1/400, 1/576,
1/1200 , 1/2400, 1/4800, 1/10000
(Adjustable only when MODE in the EXPOSURE menu is set to FULL AUTO, GAIN Pri or IRIS Pri.)
MIN SPEED For the 59.94 frame rate of video output: 1/8, 1/15, 1/30, 1/50, 1/60 , 1/90, 1/100, 1/125, 1/180,
1/250, 1/350, 1/500, 1/725, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/6000, 1/10000
For the 29.97 frame rate of video output: 1/8, 1/15,
1/ 3 0 , 1/50, 1/60, 1/90, 1/100, 1/125, 1/180,
1/250, 1/350, 1/500, 1/725, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/6000, 1/10000
For the 50 frame rate of video output: 1/6, 1/12, 1/25, 1/30,
1/50 , 1/60, 1/100, 1/120, 1/150,
1/215, 1/300, 1/425, 1/600, 1/1000, 1/1250, 1/1750, 1/2500, 1/3500, 1/6000, 1/10000
For the 25 frame rate of video output: 1/6, 1/12,
1/25 , 1/30, 1/50, 1/60, 1/100, 1/120, 1/150,
1/215, 1/300, 1/425, 1/600, 1/1000, 1/1250, 1/1750, 1/2500, 1/3500, 1/6000, 1/10000
For the 23.98 frame rate of video output: 1/6, 1/12, 1/24, 1/25, 1/40,
1/4 8 , 1/50, 1/60, 1/96, 1/100,
1/120, 1/144, 1/192, 1/200, 1/288, 1/400, 1/576, 1/1200, 1/2400, 1/4800, 1/10000
(Adjustable only when MODE in the EXPOSURE menu is set to FULL AUTO, GAIN Pri or IRIS Pri.)
IRIS F2. 8 /F3.1/F3.4/F3.7/F4.0/F4.4/F4.8/F5.2/F5.6/F6.2/F6.8/F7.3/F8.0/F8.7/F9.6/F10/F11
(Adjustable only when MODE in the EXPOSURE menu is set to MANUAL or IRIS Pri.)
AE SPEED 1 ~ 48 (Adjustable only when MODE in the EXPOSURE menu is set to FULL AUTO,
GAIN Pri, SHUTTER Pri, or IRIS Pri.)
EX-COMP OFF , ON (Adjustable only when MODE in the EXPOSURE menu is set to FULL AUTO,
GAIN Pri, SHUTTER Pri or IRIS Pri.)
BACK LIGHT OFF , ON (Adjustable only when MODE in the EXPOSURE menu is set to FULL AUTO,
GAIN Pri, SHUTTER Pri or IRIS Pri.)
SPOT LIGHT OFF , ON (Adjustable only when MODE in the EXPOSURE menu is set to FULL AUTO,
GAIN Pri, SHUTTER Pri or IRIS Pri.)
LEVEL -7, -6, -5, -4, -3, -2, -1, 0 , +1, +2, +3, +4, +5, +6, +7
(Adjustable only when MODE in the EX-COMP menu is set to ON.)
GAIN POINT OFF , ON (Adjustable only when MODE in the EXPOSURE menu is set to FULL AUTO or IRIS Pri.)
(page 31)
