21
5
Attach the wire rope for fall prevention to
the attachment materials on the shelf side.
Using an M5 (3/16 inches) socket cap screw (not
supplied), attach it to the attachment materials
different from the one to which the shelf containing
the ceiling bracket (B) is attached.
6
Aligning the a hole in the front of the ceiling
bracket (A) to the
◊
hole of the ceiling
bracket (B), push in the camera unit, and
turn the camera with the ceiling bracket (A)
clockwise to temporarily secure the
camera.
Wire rope
(supplied)
M5 ( 3 /16 inch) socket
cap bolt
Ceiling bracket (B)
Ceiling bracket (A)
Align
◊ mark
a mark
