MVI56E-MNETC ♦ ControlLogix Platform Diagnostics and Troubleshooting
Modbus TCP/IP Client Enhanced Communication Module User Manual
ProSoft Technology, Inc. Page 99 of 183
February 3, 2013
4.2.6 Monitoring MNETC Server Information
Use the MNETC SERVER menu to view the configuration and status information
for the MNETC server.
Note: To use the server capabilities, your MVI56E-MNETC module needs to have firmware version
3.01 or higher, and your MVI56E-MNETC Add-On Instruction needs to be version 1.8 or higher.
Earlier versions do not support server capabilities.
Config
Use the Configuration menu to view configuration settings for MNETC servers
connected to the MNETC Client.
The information on this menu corresponds with the configuration information in
the MNETC Servers settings in ProSoft Configuration Builder (page 46).
Status
Use the Status menu to view the status of each MNETC server connected to the
MNETC Client 0. During normal operation, the number of requests and
responses should increment, while the number of errors should not change.
4.2.7 Monitoring MNET Client Information
Use the MNET CLIENT x menu to view the configuration and status information
for the MNET Client(s).
Config
Use the Configuration menu to view configuration settings for MNET Client x.
The information on this menu corresponds with the configuration information in
the MNET Client x settings in ProSoft Configuration Builder.
Status
Use the Status menu to view status for MNET Client x. During normal operation,
the number of requests and responses should increment, while the number of
errors should not change.
Command List
Use the Command List menu to view the command list settings for MNET Client
x. The information on this menu corresponds with the MNET Client x Commands
settings in ProSoft Configuration Builder.
Use the scroll bar on the right edge of the window to view each MNET Client
command.
