Unformatted Pass-Through Block (9996)
When the unformatted pass-through mode (code 1) is selected, information is
passed from the module to the processor with a block identification code of 9996.
Word 2 of this block contains the length of the message, and the message starts
at word 3. Other controller tags are required to store the controlled values
contained in these messages.
Pass-Through Block 9996 from Module to Processor
Word Offset Description Length
0 0 1
1 9996 1
2 Number of bytes in Modbus msg 1
3 Reserved (always 0) 1
4 to 248 Modbus message received 245
249 9996 1
The ladder logic should copy and parse the received message and control the
processor as expected by the Client device. The processor responds to the pass-
through block with a write block.
Response Block 9996 from Processor to Module
Word Offset Description Length
0 9996 1
1 to 247 Spare 247
This informs the module that the command has been processed and can be
cleared from the pass-through queue.
Set Module IP Address Block (9990)
Block Request from Processor to Module
Word Offset Description Length
0 9990 1
1 First digit of dotted IP address 1
2 Second digit of dotted IP address 1
3 Third digit of dotted IP address 1
4 Last digit of dotted IP address 1
5 to 247 Reserved 243
