User Manual of WNAP-7206
-41-
Figure 5-5-3 WAN – Static IP
The page includes the following fields:
Object Description
 WAN Connections Select Static (Fixed IP) from the list.
 IP Address
Enter the IP address in dotted-decimal notation provided by
your ISP.
 Subnet Mask
Enter the subnet Mask in dotted-decimal notation provided by
your ISP, usually is 255.255.255.0
 Default Gateway
(Optional) Enter the gateway IP address in dotted-decimal
notation provided by your ISP.
 MTU Size (in bytes)
The normal MTU (Maximum Transmission Unit) value for most
Ethernet networks is 1500 Bytes. For some ISPs you need to
modify the MTU. But this is rarely required, and should not be
done unless you are sure it is necessary for your ISP
connection.
 Primary DNS Server
(Optional) Enter the DNS IP address in dotted-decimal notation
provided by your ISP.
 Secondary DNS Server
(Optional) Enter another DNS IP address in dotted-decimal
notation provided by your ISP.
