User Manual of WNAP-7206
-138-
5.16.4 Speed Test
Selecting “System Tools > Speed Test” helps to test the connection speed to and from any reachable IP
address on current network, especially when we are building wireless network between devices which are far
away from each other. It should be used for the preliminary throughput estimation between two network devices.
Figure 5-16-4-1 Speed Test
This function is only available in Standard AP Mode.
The page includes the following fields:
Object Description
 Destination IP The Remote device's IP address.
 Packet Size
Specifies the size of packet sent. The default is 1500, and the
range is 1000~65535.
 Packet Num
Specifies the number of packet sent. The default is 10000, and the
range is 1000~100,000.
 Transmit Estimate the outgoing throughput (Tx).
 Receive Estimate the ingoing throughput (Rx).
 Run Test Click the Run Test button to start the speed test procedure.
