Specifications
73
Table 38 Liebert XDV8 dimensions—domestic and export
Model
Shipping Dimensions
Length x Width x Height
inches (mm)
Unit Dimensions Unpacked
Length x Width x Height
inches (mm)
Domestic Export Unit Only
All Models
48 x 40 x 24-1/4
(1219 x 1016 x 616)
45-4/5 x 30-3/4 x 33
(1163 x 781 x 839mm)
39-1/2 x 22-7/8 x 14
(1003 x 581 x 356)
Table 39 Liebert XDV10 dimensions—domestic and export
Model
Shipping Dimensions
Length x Width x Height
inches (mm)
Unit Dimensions Unpacked
Length x Width x Height
inches (mm)
Domestic Export Unit Only
All Models
48 x 40 x 24-1/4
(1219 x 1016 x 616)
45-4/5 x 30-3/4 x 33
(1163 x 781 x 839mm)
39-1/2 x 22-7/8 x 14
(1003 x 581 x 356)
Table 40 Liebert XDCF specifications
Models
XD-CF-10-TP-0, XD-CF-10-TPE-0
XD-CF Top EXP, XD-CF-10-BPE-0
XD-CF BTM EXP, XD-CF-10-BP-0
Cooling capacity, maximum 10kWH / 2.8 Tons / 34,000 BTUh
Conditions
55°F (13°C) entering fluid temperature,
50°F (10°C) or lower dew point
Dimensions, inches (mm)
Height – including pipe connections 31-3/8" (797mm)
Width 13-7/16" (341mm)
Depth 7-5/16" (186mm)
Weight, lb (kg)
Unit only 18 (8.2)
Shipping weight 30 lb. (13.06 kg)
Pipe connections
Refrigerant Supply
from Liebert XDP/Liebert XDC
1/2" threaded one-shot coupling on the unit
Refrigerant Return
to Liebert XDP/Liebert XDC
5/8" threaded one-shot coupling on the unit
Cabinet exterior finish Gray
Agency
Safety CSA — CE
