Emerson Liebert Xtreme Density - Manual (Page 27)

Designing a Liebert XD Solution
21
Figure 21 Liebert XDV units mounted on racks emitting 8kW of heat top view
Figure 22 Liebert XDV units mounted on racks emitting 16kW of heat top view
Downflow
Cooling
Unit
Downflow
Cooling
Unit
XDVs Mounted
on Equipment Racks
Circuit 1 Circuit 2 Circuit 3
Perforated
Raised
Floor Tiles Interlaced piping arrangement
for enhanced protection
Downflow
Cooling
Unit
Downflow
Cooling
Unit
Perforated
Raised
Floor Tiles
XDOs Mounted
on Equipment Racks
Circuit 4 Circuit 5 Circuit 6
XDVs Mounted
on Equipment Racks
Circuit 3 Circuit 1 Circuit 2
Interlaced piping
arrangement
for enhanced
protection
