Liebert XD Cooling Modules—Liebert XDO, Liebert XDV, Liebert XDH and Liebert XDCF
44
Figure 43 Liebert XDH dimensions
Figure 44 Supply and return piping connections
78"
(1981mm)
42
(1067mm)
FRONT
FRONT
12" (305mm)
80"
(2032mm)
Top of Liebert XDH
Detail “A”
Rear
of Liebert
XDH
7/8" Return, Lower
Refrigeration Circuit
7/8" Return, Upper
Refrigeration Circuit
Detail "A"
6-1/16"
(154mm)
5"
(127mm)
Rear of XDH
DPN001180
Page 2, Rev. 0
4-1/8"
(105mm)
2-1/16"
(52mm)
3-11/16"
(94mm)
1-3/8"
(35mm)
1/2" Supply, Lower
Refrigeration Circuit
1/2" Supply, Upper
Refrigeration Circuit
