Table 10, Liebert xdo/liebert xdh/liebert xdv/liebert xdcf – Emerson Liebert Xtreme Density User Manual
Page 33
Designing a Liebert XD Solution
27
Table 10
R-134a refrigerant charge for Flex Pipe connector lines to and from any model
Liebert XDO/Liebert XDH/Liebert XDV/Liebert XDCF
Refrigerant Charge, lb. (kg)
Metal Flex Pipe Connector Length
Supply Line Diameter 1/2"
0.3 lb. (0.14)
4 ft. Flex Pipe Liebert XDH/Liebert XDO/Liebert
XDV/Liebert XDCF supply
0.5 lb. (0.23)
6 ft. Flex Pipe Liebert XDH/Liebert XDO/Liebert
XDV/Liebert XDCF supply
0.7 lb. (0.32)
8 ft. Flex Pipe Liebert XDH/Liebert XDO/Liebert
XDV/Liebert XDCF supply
0.8 lb. (0.36)
10 ft. Flex Pipe Liebert XDH/Liebert XDO/Liebert
XDV/Liebert XDCF supply
Return Line Diameter 5/8"
0.01 lb. (0.01)
4 ft. Flex Pipe existing Liebert XDV systems
0.02 lb. (0.01)
6 ft. Flex Pipe existing Liebert XDV systems
0.03 lb. (0.01)
8 ft. Flex Pipe existing Liebert XDV systems
0.03 lb. (0.01)
10 ft. Flex Pipe existing Liebert XDV systems
Return Line Diameter 1"
0.13 lb. (0.05)
4 ft Flex Pipe Liebert XDH/Liebert XDO/Liebert
XDV/Liebert XDCF supply
0.2 lb. (0.09)
6 ft Flex Pipe Liebert XDH/Liebert XDO/Liebert
XDV/Liebert XDCF supply
0.27 lb. (0.12)
8 ft Flex Pipe Liebert XDH/Liebert XDO/Liebert
XDV/Liebert XDCF supply
0.33 lb. (0.15)
10 ft Flex Pipe Liebert XDH/Liebert XDO/Liebert
XDV/Liebert XDCF supply
