System Description
6
1.6 Liebert XDCF
The Liebert XDCF is a self-contained module designed to cool Egenera’s BladeFrame EX cabinets and
equipment without exhausting heat into the room. Two modules (top and bottom) may be mounted on
the rear of a BladeFrame cabinet. CF modules consist of a sheet-metal frame, coil and filter dryer. It
has no moving parts and needs no electricity.
The unit is available with optional, flexible metal pipes with quick-connect couplings at each end for
easy connection to the refrigerant distribution pipes.
Figure 8 Liebert XDCF units on BladeFrame EX cabinets
