JQE 150-1.5MVPY-26956 ASSEMBLY A5 (Figure 7-7) CODE: 2362735
REFERENCE
DESIGNATOR
QTY. DESCRIPTION
MFRS. NAME & PART NO.
(SEE BOTTOM NOTE)
KEPCO
PART NO.
REC. SPARE
PART QTY.
NOTE: REPLACEMENT PARTS MAY BE ORDERED FROM KEPCO, INC. ORDERS SHOULD INCLUDE KEPCO PART NUMBER AND DESCRIPTION.
PLEASE NOTE: THE MANUFACTURER'S NAME AND PART NUMBER LISTED FOR EACH ITEM ON REPLACEMENT PARTS LISTS REPRESENTS AT
LEAST ONE SOURCE FOR THAT ITEM AND IS LISTED SOLELY FOR THE CONVENIENCE OF KEPCO EQUIPMENT OWNERS IN OBTAINING
REPLACEMENT PARTS LOCALLY. WE RESERVE THE RIGHT TO USE EQUIVALENT ITEMS FROM ALTERNATE SOURCES. KEPCO, INC.
JQE 26956 SVC 08-1111 7-19(7-20 Blank)
KEPCO REPLACEMENT PARTS LIST
CR1 1 RECT., SI RECTIFIER,
400V 5 A 50A300A DIOTEC ELECTRONICS
GP604 124-0348 1
CR203 1 RECT., THYRISTOR (SCR),
300V 16A INTERNATIONAL RECT.
IRC30C 124-0277 1
J1 1 JACK, SOCKET, POWER, CONNEC-
TOR, 3 PINS HEADER, PC MT JST CORP.
B3B-XH-A 143-0800 1
J2 1 JACK, SOCKET, POWER, CONNEC-
TOR, 2 PINS HEADER, PC MT JST CORP.
B2B-XH-A 143-0799 1
J4, J5, J6, J7, J9,
J12 6 JACK, QUICK CONNECT (MALE),
PC MOUNT ZIERICK MIDWEST
82237-21 107-0362 1
J10, J11 2 JACK, QUICK CONNECT (MALE),
PC MT., VERTICAL ZIERICK MIDWEST
K22053-22 107-0384 1
TB501 1 TERMINAL BLOCK,
STRIP, PC MT, 8 CKTS CURTIS INDUSTRIES
SEIPX08 167-1537 1
TB502, TB503 2 TERMINAL BLOCK,
STRIP, PC MT, 3 CKTS CURTIS INDUSTRIES
SEIPX03 167-1538 1
