JQE 150-1.5MVPY-26956
ASSEMBLY A4 (Figure 7-6)
CODE: 2362737
REFERENCE
DESIGNATOR
QTY.
DESCRIPTION
MFRS. NAME & PART NO.
(SEE BOTTOM NOTE)
KEPCO
PART NO.
REC. SPARE
PART QTY.
NOTE: REPLACEMENT PARTS MAY BE ORDERED FROM KEPCO, INC. ORDERS SHOULD INCLUDE KEPCO PART NUMBER AND DESCRIPTION.
PLEASE NOTE: THE MANUFACTURER'S NAME AND PART NUMBER LISTED FOR EACH ITEM ON REPLACEMENT PARTS LISTS REPRESENTS AT
LEAST ONE SOURCE FOR THAT ITEM AND IS LISTED SOLELY FOR THE CONVENIENCE OF KEPCO EQUIPMENT OWNERS IN OBTAINING
REPLACEMENT PARTS LOCALLY. WE RESERVE THE RIGHT TO USE EQUIVALENT ITEMS FROM ALTERNATE SOURCES. KEPCO, INC.
SVC08-1111
7-15
KEPCO
REPLACEMENT PARTS LIST
CR5, CR7, CR8
3
RECT., SWITCHING DIODE,
75V, 0.4A
AMERICAN POWER
1N4148-AMMO
124-0437
1
CR9
1
RECT., SI RECTIFIER,
AX. LEADS, 3000V, 200MA
RECTRON, USA
R3000-F
124-0178
1
C1
1
CAP., ELECTROLYTIC, AX. LEADS,
140UF, +100 -10%, 40V
SANGAMO COMPONE
052FE141Q040B
117-0706
1
C2, C4, C5, C7, C8,
C10, C11,
7
CAP., CERAMIC,
0.1UF, 10%, 50V
VISHAY AMERICAS
A104K15X7R5-UAA
117-1052
1
C12
1
CAP., TANTALUM,
4.7UF, 10%, 15V
SPRAGUE CAPACIT
173D475X9015VW
117-1112
1
C13
1
CAP., CERAMIC,
1000PF, 10%, 200V
VISHAY BC COMPO
A102K15X7RK5-UAA
117-1084
1
C3
1
CAP., CERAMIC,
0.047UF, 10%, 50V
BC COMPONENTS (
A473K17X7RFVVWJ
117-1054
1
C6, C9
2
CAP., CERAMIC,
0.01UF, 10%, 50V
VISHAY BC COMPO
A103K15X7RF5-UAA
117-1053
1
IC1
1
I.C. ADJ. REFERENCE
(2.5-37V) 600UA-100MA ,
MOT.
TL431AILP
250-0239
1
IC2
1
I.C. PRECISION SINGLE SUPPLY
OP.AMP
PMI
OP-90GP
250-0216
1
IC3
1
I.C. DUAL VOLTAGE COMPARATOR
OP.AMP.
NAT.
LM393AN
250-0228
1
IC4
1
I.C. PRECISION INSTRUMENTATION
AMPLIFIER
BURR-BROWN
INA118P
250-0332
1
IC5
1
I.C. LOW INPUT OFFSET VOLTAGE
OP. AMP
PRECISN MONO
OP-07CP
250-0146
1
J1
1
JACK, SOCKET, POWER, CONNEC-
TOR, 2 PINS HEADER, PC MT
JST CORP.
B2B-XH-A
143-0799
1
J2
1
JACK, SOCKET, POWER, CONNEC-
TOR, 3 PINS HEADER, PC MT
JST CORP.
B3B-XH-A
143-0800
1
J3, J4
2
JACK, QUICK CONNECT (MALE),
PC MOUNT
ZIERICK MIDWEST
82237-21
107-0362
1
PCB
1
PCB ASSY, REV#1
KEPCO
167-1541
167-1541
1
Q1
1
TRANSISTOR, SI, NPN, SMALL SIG-
NAL
RAYTHEON MFG CO
1190094
119-0094
1
RC403, R415,
R432
3
RES., VAR., MULTITURN, TRIM-
MER, COMP. OR CERM., 10 KOHM ,
3/4W, 10%
BOURNS INCORPOR
3009P-1-103
115-2481
1
