7-8 JQE 26956 SVC 08-1111
JQE 150-1.5MVPY-26956 ASSEMBLY A1 (Figure 7-2) CODE: 2351431/2671532
REFERENCE
DESIGNATOR
QTY. DESCRIPTION
MFRS. NAME & PART NO.
(SEE BOTTOM NOTE)
KEPCO
PART NO.
REC. SPARE
PART QTY.
NOTE: REPLACEMENT PARTS MAY BE ORDERED FROM KEPCO, INC. ORDERS SHOULD INCLUDE KEPCO PART NUMBER AND DESCRIPTION.
PLEASE NOTE: THE MANUFACTURER'S NAME AND PART NUMBER LISTED FOR EACH ITEM ON REPLACEMENT PARTS LISTS REPRESENTS
AT LEAST ONE SOURCE FOR THAT ITEM AND IS LISTED SOLELY FOR THE CONVENIENCE OF KEPCO EQUIPMENT OWNERS IN OBTAINING
REPLACEMENT PARTS LOCALLY. WE RESERVE THE RIGHT TO USE EQUIVALENT ITEMS FROM ALTERNATE SOURCES. KEPCO, INC.
KEPCO REPLACEMENT PARTS LIST
C1 1 CAP., ELECTROLYTIC, AX. LEADS,
220UF, 20%, 25V ILLINOIS CAPACITOR
227TTA025M 117-0713 1
C2 1 CAP., ELECTROLYTIC, AX. LEADS,
100UF, 20%, 50V ILLINOIS CAPACITOR
107TTA050M 117-0646 1
C3, C4 2 CAP., ELECTROLYTIC, AX. LEADS,
220UF, 20%, 16V CORNELL DUBILIER
MALLORY #SKA221M016AT 117-0512 1
C5 1 CAP., MYLAR, METALLIZED,
0.1UF, 20%, 600V AMERICAN SHIZUKI
X663F 0.1 20% 600VDC 117-0316 1
C9 1 CAP., MYLAR, METALLIZED,
0.047UF, 10%, 200V SPRAGUE
192P5039 117-0362 1
C10, C11 2 CAP., TANTALUM,
6.8UF, 20%, 35V BC COMPONENTS
40MS685D035M0A 117-0968 1
C12 1 CAP., CERAMIC,
0.005UF, + 80 -20%, 500V VISHAY CERA-MIT
5TSD50RE 117-0061 1
C16-C23, C26, C27 10 CAP., CERAMIC,
0.1UF, 10%, 50V VISHAY AMERICAS
A104K15X7R5-UAA 117-1052 1
IC1 1 I.C., OPERATIONAL AMPLIFIER T.I.
UA741CP 250-0025 1
IC2 1 I.C., DUAL PRECISION OP.AMP LINEAR TECH.
LT1013CN8 250-0198 1
IC3, IC4, IC5 3 I.C., PRECISION SINGLE SUPPLY
OP.AMP PMI
OP-90GP 250-0216 1
J1 1 JACK, SOCKET, POWER, CONNEC-
TOR, 2 PINS HEADER, PC MT JST CORP.
B2B-XH-A 143-0799 1
J2 1 JACK, SOCKET, CABLE CONNEC-
TOR, 5 PINS HEADER, PC MT JST CORP.
B5B-XH-A 143-0811 1
J3 1 JACK, SOCKET, CABLE CONNEC-
TOR, 4 PINS HEADER, PC MT JST CORP.
B4B-XH-A 143-0810 1
Q2 1 TRANSISTOR, SI, NPN, SMALL SIG-
NAL RAYTHEON MFG CO
1190094 119-0094 1
Q3 1 TRANSISTOR, SI, NPN, SMALL SIG-
NAL MICROSEMI CORP.
2N3019 119-0059 1
R3 1 RES., FIX., CARBON FILM,
620 OHM , 1W, 5% 115-0496 1
R4, R19, R33 3 RES., VAR., MULTITURN, TRIM-
MER, 1 KOHM , 3/4W, 10% BOURNS INCORP
3009P-1-102 115-2456 1
R5 1 RES., FIX., CARBON FILM,
560 OHM , 1/4W, 5% IRC, INC.
CF 1/4-561-J 115-2210 1
R7, R29 2 RES., FIX., PRECISION, METAL-
FILM, 750 OHM , 1/4W, 1% IRC, INC.
GP 55 100 7500 F T&R 115-2259 1
