JQE 150-1.5MVPY-26956 ASSEMBLY A4 (Figure 7-6) CODE: 2362737
REFERENCE
DESIGNATOR
QTY. DESCRIPTION
MFRS. NAME & PART NO.
(SEE BOTTOM NOTE)
KEPCO
PART NO.
REC. SPARE
PART QTY.
NOTE: REPLACEMENT PARTS MAY BE ORDERED FROM KEPCO, INC. ORDERS SHOULD INCLUDE KEPCO PART NUMBER AND DESCRIPTION.
PLEASE NOTE: THE MANUFACTURER'S NAME AND PART NUMBER LISTED FOR EACH ITEM ON REPLACEMENT PARTS LISTS REPRESENTS AT
LEAST ONE SOURCE FOR THAT ITEM AND IS LISTED SOLELY FOR THE CONVENIENCE OF KEPCO EQUIPMENT OWNERS IN OBTAINING
REPLACEMENT PARTS LOCALLY. WE RESERVE THE RIGHT TO USE EQUIVALENT ITEMS FROM ALTERNATE SOURCES. KEPCO, INC.
SVC08-1111 7-17
KEPCO REPLACEMENT PARTS LIST
fi
R430 1 RES., VAR., MULTITURN, TRIM-
MER, COMP. OR CERM., 500 OHM ,
3/4W, 10% BOURNS INCORP
3009P-1-501 115-2398 1
TP1-TP7 7 TEST POINT, 0.1” LEAD SPACING COMPONENTS CORP
ATP-402-10 173-0029 1
