JQE 150-1.5MVPY-26956 POWER SUPPLY (Figure 7-1) CODE: 1306457
REFERENCE
DESIGNATOR
QTY. DESCRIPTION
MFRS. NAME & PART NO.
(SEE BOTTOM NOTE)
KEPCO
PART NO.
REC. SPARE
PART QTY.
KEPCO REPLACEMENT PARTS LIST
NOTE: REPLACEMENT PARTS MAY BE ORDERED FROM KEPCO, INC. ORDERS SHOULD INCLUDE KEPCO PART NUMBER AND DESCRIPTION.
PLEASE NOTE: THE MANUFACTURER'S NAME AND PART NUMBER LISTED FOR EACH ITEM ON REPLACEMENT PARTS LISTS REPRESENTS
AT LEAST ONE SOURCE FOR THAT ITEM AND IS LISTED SOLEY FOR THE CONVENIENCE OF KEPCO EQUIPMENT OWNERS IN OBTAINING
REPLACEMENT PARTS LOCALLY. WE RESERVE THE RIGHT TO USE EQUIVALENT ITEMS FROM ALTERNATE SOURCES. KEPCO, INC.
7-4 26956 SVC 081111
@A1 1 MOUNTING BKT. KEPCO
128-1966 128-1966 1
@A1 1 MOUNTING BKT. KEPCO
128-1967 128-1967 1
@B201 1 BLADE, FAN
4.25 DIA, 7/32 HUB KEPCO
149-0031 149-0031 1
@C201 1 CAP. BKT. CORNELL DUBILIER
115058-06 128-0025 1
B201 1 FAN, 3-POLE MOTOR
115VAC, 50/60HZ FASCO ( JAKEL)
J238-087-8157 148-0049 1
CB101 1 CIRCUIT BREAKER, (HYDRAULIC
MAGNETIC), 2POLE 250VAC 1A/3A SENSATA TECHNOLOGY
UPGH-14-725-2 127-0388 1
CR201/CR202/
C205/C206/C207 1 RECT. ASS’Y (COMPONENTS
LISTED SEPARATELY) KEPCO
124-0397 124-0397 1
CR201, CR202 2 RECT., SI RECTIFIER,
600V, 15A INTERNATIONAL RECT,
1N3214 124-0213 1
C201 1 CAP., ELECTROLYTIC, CAN-TYPE,
1000UF, + 50 -20%, 350V CORNELL DUBILIER
DCMC102T350AC2A 117-1302 1
C204 1 CAP., ELECTROLYTIC, CAN-TYPE,
440UF, + 50 -10%, 200V CORNELL DUBILIER
500441T200AB2A 117-0760 1
C205 1 CAP., CERAMIC,
0.02UF, 20%,1000V STANDARD RADIO VISHAY
5GAS20 117-0104 1
C206, C207 2 CAP., CERAMIC,
0.01UF, 20%, 2000V VISHAY CERA-MIT
20GAS10 117-0059 1
DS101 1 DEVICE, SIGNALING, NEON W/INT
RES, RD LENS, 115VAC CHICAGO MIN-
IATU~2110QAX1 152-0087 1
M101 1 METER, DC, SINGLE SCALE,
0- 1.5A, 2.0”, 2% HONEYWELL
MODEL 504 135-0422 1
M102 1 METER, DC, SINGLE SCALE,
0- 150V, 2.0” 2% HONEYWELL
MODEL 504 135-0472 1
R101 1 RES., VAR., MULTITURN, POTEN-
TIOMETER, 5 KOHM , 2W, 5% BOURNS INCORPORP
3590S-2-502 115-1261 1
R102 1 RES., VAR., MULTITURN, POTEN-
TIOMETER, 100 KOHM , 2W, 5% BOURNS INCORPORP
3590S-2-104 115-1645 1
R103 1 RES., VAR., MULTITURN, POTEN-
TIOMETER, 0.5 KOHM , 2W, 5% BOURNS INCORPORP
3590S-1-501L 115-3191 1
R201 1 RES., FIX., POWER, AX. LEADS,
7.5 OHM, 5W, 5% VISHAY DALE
CW0057R500JB12 115-0982 1
R202 1 RES., FIX., POWER, AX. LEADS,
20 KOHM, 5W, 5% VISHAY DALE
CW00520K00JB12 115-1833 1
