JQE 150-1.5MVPY-26956 ASSEMBLY A3 (Figure 7-3) CODE: 1130378
REFERENCE
DESIGNATOR
QTY. DESCRIPTION
MFRS. NAME & PART NO.
(SEE BOTTOM NOTE)
KEPCO
PART NO.
REC. SPARE
PART QTY.
NOTE: REPLACEMENT PARTS MAY BE ORDERED FROM KEPCO, INC. ORDERS SHOULD INCLUDE KEPCO PART NUMBER AND DESCRIPTION.
PLEASE NOTE: THE MANUFACTURER'S NAME AND PART NUMBER LISTED FOR EACH ITEM ON REPLACEMENT PARTS LISTS REPRESENTS AT
LEAST ONE SOURCE FOR THAT ITEM AND IS LISTED SOLELY FOR THE CONVENIENCE OF KEPCO EQUIPMENT OWNERS IN OBTAINING
REPLACEMENT PARTS LOCALLY. WE RESERVE THE RIGHT TO USE EQUIVALENT ITEMS FROM ALTERNATE SOURCES. KEPCO, INC.
JQE 26956 SVC 08-1111 7-11
KEPCO REPLACEMENT PARTS LIST
FIGURE 7-3. JQE 150-1.5MVPY-26956 A3 ASSEMBLY, COMPONENT LOCATIONS
Q301-Q312 12 TRANSISTOR, SI, NPN, POWER ON SEMICONDUCTOR
2N3773 119-0091 1
S301 1 SWITCH, THERMOSTAT (N.O.), SW-
THERMO SP ST HONEYWELL/ELMWOOD
2450G-8081-0084 127-0248 1
