7-16 SVC08-1111
JQE 150-1.5MVPY-26956 ASSEMBLY A4 (Figure 7-6) CODE: 2362737
REFERENCE
DESIGNATOR
QTY. DESCRIPTION
MFRS. NAME & PART NO.
(SEE BOTTOM NOTE)
KEPCO
PART NO.
REC. SPARE
PART QTY.
NOTE: REPLACEMENT PARTS MAY BE ORDERED FROM KEPCO, INC. ORDERS SHOULD INCLUDE KEPCO PART NUMBER AND DESCRIPTION.
PLEASE NOTE: THE MANUFACTURER'S NAME AND PART NUMBER LISTED FOR EACH ITEM ON REPLACEMENT PARTS LISTS REPRESENTS
AT LEAST ONE SOURCE FOR THAT ITEM AND IS LISTED SOLELY FOR THE CONVENIENCE OF KEPCO EQUIPMENT OWNERS IN OBTAINING
REPLACEMENT PARTS LOCALLY. WE RESERVE THE RIGHT TO USE EQUIVALENT ITEMS FROM ALTERNATE SOURCES. KEPCO, INC.
KEPCO REPLACEMENT PARTS LIST
RN2A/ RN2B 2 RES, NET, RATIO 30:1
RN2A: 150K/RN2B: 4.99K PRECISION RESIS
PR9162 234-0038 1
R1 1 RES., FIX., CARBON FILM,
330 OHM , 2W, 5% RCD COMPONENTS
CF200S 3300 J TB 115-0882 1
R2 1 RES., FIX., CARBON FILM,
510 OHM , 1/2W, 5% KOA/SPEER
CF1/2 511 J T52A 115-0824 1
R3 1 RES., FIX., PRECISION, METAL-
FILM, 4.02 KOHM , 1/4W, 1% VISHAY DALE
CCF554K02FKE36 115-3021 1
R4 1 RES., FIX., POWER, AX. LEADS,
0.5 OHM , 3W, 3% VISHAY DALE
CW02BR5000HS70 115-1880 1
R5, R8 2 RES., FIX., CARBON FILM,
1 KOHM , 1/4W, 5% IRC, INC.
CF-1/4 102 J T&R 115-2238 1
R6 1 RES., FIX., PRECISION,
2.49 KOHM , 1/8W, 0.1% VISHAY DALE
PTF-56 2K490 B T-13 R36 115-2970 1
R7 1 RES., FIX., CARBON FILM,
10 OHM , 1/4W, 5% IRC, INC.
CF 1/4-100-J 115-2230 1
R9 1 RES., FIX., PRECISION, METAL
FILM, 49.9 KOHM , 1/8W, 1% VISHAY DALE
CMF5549K900FEEA 115-2755 1
R10 1 RES., FIX., PRECISION, METAL-
FILM, 7.5 KOHM , 1/4W, 1% IRC
CES RN60D7501F 115-1853 1
R11, R26, R27,
R28, R29 5 RES., FIX., PRECISION, METAL
FILM, 4.99 KOHM , 1/8W, 1% VISHAY DALE
CFF-55 4991 F R36 115-2401 1
R12, R13, R22 3 RES., FIX., PRECISION, METAL
FILM, 1 KOHM , 1/4W, 1% VISHAY DALE
CCF-55-1001-F-R36 115-2180 1
R15 1 RES., FIX., PRECISION, METAL
FILM, 15 KOHM , 1/8W, 1% IRC, INC.
GP55 100 1502 F T&R 115-2452 1
R16 1 RES., FIX., CARBON FILM,
100 OHM , 1/4W, 5% IRC, INC.
CF 1/4 101 J T&R 115-2231 1
R19 1 RES., FIX., PRECISION, METAL-
FILM, 150 OHM , 1/4W, 1% VISHAY DALE
CCF-55 115-2091 1
R20 1 RES., FIX., PRECISION, METAL
FILM, 2 KOHM , 1/8W, 1% VISHAY DALE
CCF-55 2001 F R36 115-2334 1
R23, R25, R31 3 RES., FIX., PRECISION, METAL
FILM, 10 KOHM , 1/8W, 1% VISHAY DALE
CCF-55-1002-F-1/4W 115-2174 1
R24 1 RES., FIX., POWER, SHUNT (4
TERMINAL), 0.01 OHM , 3W, 1% ISOTEK CORP
PBV-R010-1.0 115-3046 1
R33 1 RES., FIX., CARBON FILM,
2.2 KOHM , 1/4W, 5% RCD COMPONENTS
CF25 2201 J TB 115-2382 1
R34, R35, R36,
R37 4 RES., FIX., METAL FILM,
100 KOHM , 1/8W, 0.1% VISHAY DALE
CMF-55 1003 B T-9 R36 115-2864 1
