7-12 JQE 26956 SVC 08-1111
JQE 150-1.5MVPY-26956 ASSEMBLY A3A1 (Figure 7-4) CODE: 2361761
REFERENCE
DESIGNATOR
QTY. DESCRIPTION
MFRS. NAME & PART NO.
(SEE BOTTOM NOTE)
KEPCO
PART NO.
REC. SPARE
PART QTY.
NOTE: REPLACEMENT PARTS MAY BE ORDERED FROM KEPCO, INC. ORDERS SHOULD INCLUDE KEPCO PART NUMBER AND DESCRIPTION.
PLEASE NOTE: THE MANUFACTURER'S NAME AND PART NUMBER LISTED FOR EACH ITEM ON REPLACEMENT PARTS LISTS REPRESENTS
AT LEAST ONE SOURCE FOR THAT ITEM AND IS LISTED SOLELY FOR THE CONVENIENCE OF KEPCO EQUIPMENT OWNERS IN OBTAINING
REPLACEMENT PARTS LOCALLY. WE RESERVE THE RIGHT TO USE EQUIVALENT ITEMS FROM ALTERNATE SOURCES. KEPCO, INC.
KEPCO REPLACEMENT PARTS LIST
FIGURE 7-4. JQE 150-1.5MVPY-26956 A3A1 ASSEMBLY, COMPONENT LOCATIONS
R301-303, R306-
308 6 RES., FIX., POWER, AX. LEADS,
1 OHM , 3W, 5% VISHAY DALE ELE
CW02B1R000JS70 115-0499 1
R311, R312 2 RES., FIX., CARBON FILM,
120 OHM , 1/2W, 5% IRC
GBT-1/2 115-1136 1
