JQE 150-1.5MVPY-26956 ASSEMBLY A1 (Figure 7-2) CODE: 2351431/2671532
REFERENCE
DESIGNATOR
QTY. DESCRIPTION
MFRS. NAME & PART NO.
(SEE BOTTOM NOTE)
KEPCO
PART NO.
REC. SPARE
PART QTY.
NOTE: REPLACEMENT PARTS MAY BE ORDERED FROM KEPCO, INC. ORDERS SHOULD INCLUDE KEPCO PART NUMBER AND DESCRIPTION.
PLEASE NOTE: THE MANUFACTURER'S NAME AND PART NUMBER LISTED FOR EACH ITEM ON REPLACEMENT PARTS LISTS REPRESENTS AT
LEAST ONE SOURCE FOR THAT ITEM AND IS LISTED SOLELY FOR THE CONVENIENCE OF KEPCO EQUIPMENT OWNERS IN OBTAINING
REPLACEMENT PARTS LOCALLY. WE RESERVE THE RIGHT TO USE EQUIVALENT ITEMS FROM ALTERNATE SOURCES. KEPCO, INC.
JQE 26956 SVC 08-1111 7-7
KEPCO REPLACEMENT PARTS LIST
Q1 1 TRANSISTOR, SI, NPN, POWER,
2N3584 250N 2 35 C NI CENTRAL SEMICON
2N3584 119-0104 1
R1 1 RES., FIX., CARBON FILM,
300 OHM , 1/2W, 5% 115-0783 1
R2 1 RES., FIX., CARBON FILM,
3 KOHM , 1/4W, 5% IRC, INC.
CF-1/4 302 J T&R 115-2294 1
R6 1 RES., FIX., PRECISION, METAL
FILM, 5.62 KOHM , 1/8W, 1% VISHAY DALE
CCF555K62FKR36 115-2409 1
R8 1 RES., FIX., PRECISION, METAL
FILM, 3.74 KOHM , 1/8W, 1% VISHAY DALE
CCF-55 3741 F R36 115-2512 1
R23 1 RES., FIX., CARBON FILM,
82 OHM , 1/2W, 5% YAGEO
CFR-50 JTJ52 300R 115-1243 1
R24 1 RES., FIX., POWER, AX. LEADS,
16 KOHM , 3W, 5% RCD COMPONENTS
RCD 135 163 JTW T & R 115-2137 1
R42, R43, R44,
R45 4 RES., FIX., METAL FILM,
4.99 KOHM , 1/8W, 0.1% VISHAY DALE
PTF-56 4K99 B T-13 R36 115-2863 1
R53 1 RES., FIX., METAL FILM,
10.7 KOHM , 1/8W, 0.1% VISHAY DALE
CMF5510K700BERE 115-2880 1
R57 1 RES., FIX., PRECISION,
5 OHM , 1W, 1% VISHAY DALE
RS-1A-5 OHM 1% 115-1374 1
A1 ASSEMBLY COMMON PARTS
(SEE PREVIOUS LISTING FOR A1 ASSEMBLY UNIQUE PARTS)
CR1, CR6, CR8 3 RECT., ENCAPSULATED BRIDGE
200V 1A FAIRCHILD
W02G 124-0346 1
CR2, CR10, CR11,
CR12, CR13, CR19 6 DIODE, ZENER,
6.8V, 5% MICROSEMI CORP.
1N5235BTR 121-0080 1
CR2, CR17 2 DIODE, REFERENCE,
6.2V, 5% ON SEMICONDUCTOR
1N821 TAPE/REEL 121-0041 1
CR4, CR5 2 RECT., SI, AX. LEADS,
3000V, 200MA RECTRON, USA
R3000-F 124-0178 1
CR7 1 RECT., SI
100V 1.5A DIOTEC ELECTRON
1N5392 124-0133 1
CR9 1 DIODE, ZENER,
6.5V, 5% AMERICAN POWER
1N763-1 121-0028 1
CR14, 15, 16, 18,
22, 23 6 RECT., SWITCHING DIODE,
75V 0.4A AMERICAN POWER
1N4148-AMMO 124-0437 1
CR20, CR21 2 DIODE, ZENER,
5.6V, 5% AMERICAN POWER DEV.
1N752A 121-0066 1
