JQE 150-1.5MVPY-26956 ASSEMBLY A1 (Figure 7-2) CODE: 2351431/2671532
REFERENCE
DESIGNATOR
QTY. DESCRIPTION
MFRS. NAME & PART NO.
(SEE BOTTOM NOTE)
KEPCO
PART NO.
REC. SPARE
PART QTY.
NOTE: REPLACEMENT PARTS MAY BE ORDERED FROM KEPCO, INC. ORDERS SHOULD INCLUDE KEPCO PART NUMBER AND DESCRIPTION.
PLEASE NOTE: THE MANUFACTURER'S NAME AND PART NUMBER LISTED FOR EACH ITEM ON REPLACEMENT PARTS LISTS REPRESENTS AT
LEAST ONE SOURCE FOR THAT ITEM AND IS LISTED SOLELY FOR THE CONVENIENCE OF KEPCO EQUIPMENT OWNERS IN OBTAINING
REPLACEMENT PARTS LOCALLY. WE RESERVE THE RIGHT TO USE EQUIVALENT ITEMS FROM ALTERNATE SOURCES. KEPCO, INC.
JQE 26956 SVC 08-1111 7-9
KEPCO REPLACEMENT PARTS LIST
R9 1 RES., FIX., CARBON FILM,
220 OHM , 1/2W, 5% YAGEO
CF-50 115-0470 1
R10 1 RES., FIX., PRECISION, METAL-
FILM, 82.5 KOHM , 1/4W, 1% VISHAY DALE
RN60D 115-2012 1
R11 1 RES., FIX., CARBON FILM,
3.9 KOHM , 1W, 5% OHMITE
OM3925A52 115-2122 1
R12 1 RES., FIX., CARBON FILM,
1.5 KOHM , 1W, 5% YAGEO
CFR-100 JTJ52 1K5 115-0664 1
R13, R28 2 RES., FIX., CARBON FILM,
2.2 KOHM , 1/4W, 5% RCD COMPONENTS
CF25 2201 J TB 115-2382 1
R14 1 RES., VAR., MULTITURN, TRIM-
MER, 100 KOHM , 3/4W, 10% BOURNS INCORP
3009P-1-104 115-2399 1
R15 1 RES., FIX., PRECISION, METAL
FILM, 10 KOHM , 1/8W, 1% VISHAY DALE
CCF-55-1002-F-1/4W 115-2174 1
R16 1 RES., VAR., MULTITURN, TRIM-
MER, 500 OHM , 3/4W, 10% BOURNS INCORP
3009P-1-501 115-2398 1
R20, R25, R27,
R58 4 RES., FIX., CARBON FILM,
10 OHM , 1/4W, 5% IRC, INC.
CF 1/4-100-J 115-2230 1
R21 1 RES., FIX., CARBON FILM,
12 KOHM , 1/4W, 5% IRC
GBT 1/4 115-2276 1
R22 1 RES., FIX., PRECISION, METAL
FILM, 301 OHM , 1/8W, 1% IRC
CEA TYPE RN55D3010F 115-2261 1
R30, R31 2 RES., FIX., PRECISION, METAL
FILM, 43.2 KOHM , 1/8W, 1% IRC
CEA RN55D4322F 115-2380 1
R32, R52 2 RES., FIX., PRECISION, METAL-
FILM, 511 OHM , 1/4W, 1% RCD COMPONENTS
RCD GP55-5110-FTW 115-2092 1
R34 1 RES., FIX., PRECISION, METAL
FILM, 210 OHM , 1/8W, 1% IRC
RN55D100F 115-2177 1
R37 1 RES., FIX., PRECISION, METAL
FILM, 5.62 KOHM , 1/8W, 1% VISHAY DALE
CCF555K62FKR36 115-2409 1
R38, R49 2 RES., FIX., PRECISION, METAL
FILM, 1.24 KOHM , 1/8W, 1% VISHAY DALE
CCF-50 1241 F R36 115-2507 1
R39, R40, R50,
R51 4 RES., FIX., PRECISION,
2.49 KOHM , 1/8W, 0.1% VISHAY DALE
PTF-56 2K490 B T-13 R36 115-2970 1
R41, R48 2 RES., FIX., PRECISION, METAL
FILM, 100 OHM , 1/8W, 1% VISHAY DALE
CCF-55 1000 F R36 115-2598 1
R46 1 RES., FIX., PRECISION, METAL
FILM, 499 KOHM , 1/8W, 1% VISHAY DALE
CCF-55 4993 F R36 115-2309 1
R47 1 RES., FIX., PRECISION, METAL
FILM, 8.06 KOHM , 1/8W, 1% VISHAY DALE
CMF-55, 8061, F, T-0 115-2445 1
