Operation
3.6 Protection Circuitry Operation
The inverter is protected against fault conditions, and in normal usage it will be rare to see any.
However, if a condition occurs that is outside the inverter’s normal operating parameters, it will shut
down and attempt to protect itself, the battery bank, and your AC loads. If there is a condition that
causes the inverter to shut down, it may be one of the following [also refer to the Troubleshooting
section (Section 4.4) to help diagnose and clear the fault condition]:
• Low Battery – The inverter shuts off whenever the battery voltage falls to the LBCO (Low
Battery Cut Out) level—to protect the batteries from being over-discharged. After the inverter
has reached the LBCO level and turns off, it automatically restarts after one of the following
conditions are met:
1. AC power is applied and the inverter begins operating as a battery charger.
2. Battery voltage rises to the LBCI (Low Battery Cut In) level.
Refer to Table 3-1 to determine the LBCO and LBCI levels for your inverter model.
• High Battery – In the event the battery voltage approaches the HBCO (High Battery Cut
Out) level, the inverter automatically shuts down to prevent it from supplying unregulated
AC output voltage. The inverter’s status LED turns off when a high battery fault condition
occurs. The inverter automatically restarts when the battery falls to the HBCI (High Battery
Cut In) level. Refer to Table 3-1 to determine the HBCO and HBCI levels for your inverter
model.
Info: High battery voltage may be caused by excessive or unregulated voltage from
the solar panels or other external charging sources.
• Overload – During inverter and standby operation, the inverter monitors the DC and AC
current levels. In the event of a short-circuit or an overload condition for more than a few
seconds, the inverter shuts down. To start operating after this fault, the inverter must be
restarted (turned back on) once the inverter’s AC loads are reduced/removed.
• Over-temperature – If internal power components begin to exceed their safe operating
temperature level, the inverter shuts down to protect itself from damage. The inverter’s status
LED turns off to indicate the over-temperature fault condition. The inverter automatically
restarts after the unit cools down.
• Internal Fault – The inverter continually monitors several internal components and the
processor communications. If a condition occurs that does not allow proper internal operation,
the inverter shuts down to protect itself and the connected loads. The inverter needs to be
reset to start operating—refer to Section 4.4 for information on resetting the inverter.
Table 3-1, Inverter Battery Turn On/Off Levels
Inverter battery
turn ON/OFF Levels
Inverter Model
MS2000-G/
MS2012-G
MS2812-G MS4024-G
HBCO >16.9 VDC >16.9 VDC >33.8 VDC
HBCI 16.6 VDC 16.6 VDC 33.2 VDC
LBCI 12.5 VDC 12.5 VDC 25.0 VDC
LBCO*
(1 minute delay)
10.0 VDC
(9.0 - 12.2 VDC)
10.0 VDC
(9.0 - 12.2 VDC)
20.0 VDC
(18.0 - 24.4 VDC)
LBCO (immediate) 8.5 VDC 8.5 VDC 17.0 VDC
*adjustable with remote control
