Configuration and Operation
Operating Instructions Powador 12.0 TL3-20.0 TL3 Page 41
8.4 Monitor inverter
The inverter has an integrated web server. This makes it possible to monitor and record the operating state and yield
of your PV system.
You can display the recorded data using:
• The integrated LCD
• The integrated web server using an Internet-capable device connected to the Ethernet interface of the inverter
You can read the recorded data using a storage medium connected to the USB interface of the inverter, e.g. a USB stick.
8.4.1 USB interface
Use an external USB storage device to read operating data saved in the inverter.
8.4.1.1 Reading log data
NOTE
The USB interface is approved solely for use with USB flash storage devices (“USB sticks”).
The maximum available current is 100 mA. If a device with a higher power requirement is used,
the power supply for the USB interface automatically shuts down to protect the inverter from
damage.
Reading log data
1. Connect a suitable USB storage device to the USB interface on the underside of the inverter.
2. Open the “Log data display” menu.
3. Select the “Save to USB” item.
4. Select the desired log data using the 4-way button.
5. Press the OK button.
» The inverter saves the selected log data to the USB storage device.
8.4.2 Web server
The inverter has an integrated web server. After configuring the network and activating the web server in the
Settings menu, you can open the web server from an Internet browser. The language version of the website
delivered by the web server is adapted dynamically to the pre-set language preferences in your Internet browser.
If your Internet browser requests a language that is unknown to the inverter, the web server uses the menu
language set in the inverter.
8.4.2.1 Setting up the web server
Configuring the Ethernet interface
↻ You have connected the inverter to your network.
1. Open the Settings/Ethernet menu.
2. Assign a unique IP address.
3. Assign a subnet mask.
4. Assign a gateway.
5. Save your settings.
8.4.2.2 Using the web server
To avoid problems with incompatibility, use the most recent version of your Internet browser. JavaScript must be
enabled in the browser settings to display the web server correctly.
