Low-Loss Antenna Cable
A-20 Specifications
Table A-18 RBTES-L600 Cable Specifications
Specification Value
Mechanical
• Length 25 ft (7.6 m)
50 ft (15.24 m)
• Weight 0.131 lb/ft (0.20 kg/m)
• Bend Radius 1.50 in. (38.1 mm)
• Tensile Strength 350 lb (158.9 kg)
Environmental
• Temperature Range:
- Operating
- Storage -40 to +85 °C (-40 to +185 °F)
-70 to +85 °C (94 to +185 °F)
Electrical
• Cutoff Frequency 10.3 GHz
• Velocity of Propagation 87%
• Shielding Effectiveness Greater than 90 dBi
• DC Resistance
- Inner Conductor
- Outer Conductor 0.53ohms/1000ft (1.7 ohms/km)
1.2 ohms/1000ft (3.9 ohms/km)
• Peak Power 40 kW
Connector Type Reverse-N (Female on both ends)
Cable Loss 25 feet:
• 2.4 GHz: 1.1 dB
• 5.3 GHz: 1.7 dB
• 5.8 GHz: 1.8 dB
50 feet:
• 2.4 GHz: 2.2 dB
• 5.3 GHz: 3.5 dB
• 5.8 GHz: 3.6 dB
