RoamAbout 5.1-5.9 GHz 14.5 dBi 60 Degree Sector Panel Antenna
A-10 Specifications
RoamAbout 5.1-5.9 GHz 14.5 dBi 60 Degree Sector Panel Antenna
Part number RBTES‐AW‐S1460.
Note: This antenna can only be used with the RBT-1602.
Table A-9 RoamAbout 5.1-5.9 GHz 14.5 dBi Sector Panel Antenna Specifications
Specification Value
Electrical
• Frequency Range 5100 - 5900 MHz
• Gain (nominal) 14.5 dBi
• Front-to-Back Ratio > 25 dBi
• Polarization Vertical, Linear
• Nominal Impedance 50 Ohms
• 3 dB Horizontal Beamwidth 60 degrees
• 3 dB Vertical Beamwidth 14 degrees
• VSWR < 1.5:1 (or > 14 dB)
• Maximum Power 20 W
Environmental
• Temperature Range -45 °C to +75 °C (-49 °F to 167 °F)
• Storage Temperature -30 °C to +75 °C (22 °F to 167 °F)
Mechanical
• Wind Loading (frontal) > 10 Kg (200 km/h)
• Lightning Protection Direct Grounding
• Dimensions 63.5 mm W x309.9 mm L x 24.5 cm D
(2.5 in. W x 12.2 in. L x 1 in.D)
• Weight 100 g (0.220 lb)
• Radome Material ASA with UV protection
• Connector Reverse-N Male
Mounting Wall mount, pole mount
