RoamAbout 5.3 GHz 10db Omni-Directional Antenna
RoamAbout Antenna Site Preparation and Installation Guide A-11
RoamAbout 5.3 GHz 10db Omni-Directional Antenna
Part number RBTES‐AM‐M10M.
Note: This antenna can only be used with the RBT-4102, and the RBT-4102-EU.
Table A-10 5.3 GHz Omni-Directional Antenna Specifications
Specification Value
Electrical
• Frequency Range 5.15–5.35 GHz
• Gain
Omni cut plane gain measurement over the
frequency band
10 dBi +/- 1 dBi
• Polarization Vertical
• Nominal Impedance 50 Ohms
• Undulation Ratio in the Horizontal Plane 2.4 dBi (Type)
• -3 dBi Beamwidth in the Vertical Plane 8.5 degrees +/- 0.5 degrees
• Cross Polarization Level in Horizontal and
Vertical Planes
Greater than 24 dBi
• VSWR 1.5 Max (Normal and icing conditions)
• Maximum Power 20 Watts
Mechanical
• Wind-loading (in accordance with the ETS 300
019-1-4.4.1E)
139.00 km/h (86.4 mph)
• Height 429 mm (16.8 in.)
• Weight 139.000 g (.306 lb)
Mounting Mast or wall mounting
Termination Reverse-N Male
Environmental
Temperature
• Stationary -40 to +55 °C (-40 to 131 °F)
• Cyclic -40 to +55 °C (-40 to 131 °F)
Rate 0.5 °C/minute
• Humidity (Stationary) 93% @ 30 °C (86 °F)
• Vibration (Sinusoidal) +/- 3 mm / 10 m/s 2
• Shocks 250 m/s 2
