RoamAbout 2.4 GHz 10 dBi 60 Degree Sector Panel Antenna
RoamAbout Antenna Site Preparation and Installation Guide A-7
RoamAbout 2.4 GHz 10 dBi 60 Degree Sector Panel Antenna
Part number RBTES‐BG‐S1060.
Note: This antenna can only be used with the RBT-1602.
Table A-6 RoamAbout 2.4 GHz 10 dBi Directional Panel Antenna Specifications
Specification Value
Electrical
• Frequency Range 2400–2483 MHz
• Gain (nominal) > 10 dBi
• Front-to-Back Ratio > 20 dBi
• Polarization Vertical, Linear
• Nominal Impedance 50 Ohms
• 3 dB Horizontal Beamwidth 60 degrees
• 3 dB Vertical Beamwidth 65 degrees
• VSWR < 1.5:1 (or > 14 dB)
• Maximum Power 20 W
Environmental
• Temperature Range -45 °C to +75 °C (-49 °F to 167 °F)
• Storage Temperature -30 °C to +75 °C (22 °F to 167 °F)
Mechanical
• Wind Loading (frontal) > 10 Kg (125 km/h)
• Dimensions 1.143 mm W x 111.7 mm L x 25.4 cm D
(4.5 in. W x 4.4 in. L x 1 in.D)
• Weight 0.5 lb
• Lightning Protection Direct grounding
• Radome Material ASA with UV protection
• Connector Reverse-N Male
Mounting Wall mount, pole mount
