Mounting the Antenna
RoamAbout Antenna Site Preparation and Installation Guide 3-13
To mount the RoamAbout 2.4 GHz directional antenna to a narrow mast, perform the following
steps:
1.
Remove the nuts, flat and channel washers from the open end of the U‐bolt.
2.
Remove the bracket nearest to the open end of the U‐bolt.
3.
Insert the U‐bolt around the mast.
4.
Reverse the orientation of the bracket that you removed so that it is on the U‐bolt in the same
orientation as the other bracket. (That is, with the convex side of the bracket facing the closed
end of the U‐bolt and the concave side of the U‐bolt facing the open end of the U‐bolt.)
5.
Replace the nuts, flat and channel washers on the ends of the U‐bolt.
6.
Tighten the nuts until the brackets grip the mast snugly.
7.
Turn the tilt angle adjuster to the angle at which you want to mount the antenna.
8.
Repeat steps 1 through 7 to attach the second U‐bolt mount to the mast.
9.
Connect the antenna to the screws in the middle of the tilt angle adjusters on each U‐bolt.
10. After mounting the antenna, connect the antenna cables as described in “
Note: Install the channel washer on the notched side of the bracket.
