i.9 Standards Compliance
u European Standards
Figure i.50 CE Mark
The CE mark indicates that a product is in compliance with applicable European Directives for safety and environmental
regulations. It is required for engaging in business and commerce in Europe.
The applicable European Directives for this product are as follows. We declared the CE marking based on the harmonized
standards in Table i.27 .
Table i.27 European Directives
Applicable European Directive Applicable Harmonized Standards
Low Voltage Directive (2006/95/EC) IEC/EN618995-1: 2007
EMC Guidelines (2004/108/EC) IEC/EN 61800-3: 2004
Machinery Directive (2006/42/EC)
ISO/EN ISO 13849-1/AC: 2009
IEC/EN 62061: 2005 (SILCL3)
IEC/EN 61800-5-2: 2007 (SIL3)
The user(s) is solely responsible for ensuring that the end products used with this drive comply with all applicable European
directives and with other national regulations (if required).
u CE Low Voltage Directive Compliance
This drive has been tested according to European standard IEC/EN 61800-5-1, and it fully complies with the Low Voltage
Directive.
To comply with the Low Voltage Directive, be sure to meet the following conditions when combining this drive with other
devices:
n Area of Use
Do not use drives in areas with pollution higher than severity 2 and overvoltage category 3 in accordance with IEC/EN 664.
n Grounding
The drive is designed to be used in T-N (grounded neutral point) networks. If installing the drive in other types of grounded
systems, contact your Yaskawa representative for instructions. Refer to Enable the Internal EMC Filter on page 37 for details.
n Guarding Against Harmful Materials
When installing IP00/Open Type enclosure drives, use an enclosure that prevents foreign material from entering the drive
from above or below.
u EMC Guidelines Compliance
Models UooEoooo and UooWoooo have built-in EMC filters, are tested according to European standards IEC/EN
61800-3: 2004, and comply with EMC guidelines. Use drives with built-in EMC filters to comply with EMC guidelines.
n EMC Filter Installation
Installation Method
Verify the following installation conditions to ensure that other devices and machinery used in combination with drive models
UooEoooo and UooWoooo also comply with EMC guidelines.
1.
Place the drive in the enclosure.
2.
Use braided shield cable for the drive and motor wiring, or run the wiring through a metal conduit.
3.
Keep wiring as short as possible. Ground the shield on both the drive side and the motor side.
