Basic Management Configuration Chapter 1 Web Management
1-1
Chapter 1 Web Management
The WS6028 or Access Controller / AC is managed using the build in web gui.
This section will cover the process of getting connected to the device.
1.1 Configuration Preparation
To configure the AC, we recommend a stand-alone pc and a direct connection to the
device.
1.1.1 AC Management through Web
Configure the AC by using a PC configured to be in the same subnet.
The default IP address of AC is 192.168.1.1 and the subnet mask is 255.255.255.0.
The steps of creating the network connection are as below:
Step 1: setting up the environment:
Fig 1-1 Web Management Configuration Environment
As shown above, the Ethernet port for the PC is connected with the AC’s Ethernet Port 1 by a
network cable
Step 2: Setting the network connection (for example with Windows XP system):
After connecting successfully, please click the button, select ,
Double-click , then double-click
Connection>, it will show window, as shown in Fig 1-2 .
