3 Web Interface – Standard Version
the IP address and the community string in the designated fields. Each text field
accommodates up to 64 characters.
Figure 3.21 SNMP Section
3.6. Configuration Page - Sensors Tab
For each sensor, you can edit all fields in gray. All other fields are for reference. To the right of
the Value field is the corresponding Modbus Register for slave data output from that sensor.
To the right of that is the BACnet Instance number for slave interface to a Building
Management System.
Option Description
System Name Name assigned to the Wireless Gateway for SNMP system
integration.
System Contact System Contact responsible for the Wireless Gateway.
System Location Description of the Wireless Gateway location.
Communities: IP
Address
IP address used by the SNMP server to poll data from the Wireless
Gateway.
Community String Name or type of password used by the SNMP server for
communications.
Write Allows the SNMP server to write back the Wireless Gateway.
Trap Allows the Wireless Gateway to send a message to the SNMP
Management System, telling the system to initiate an alarm.
Table 3.14 SNMP Section Options
