Pulse Rate SW2-1 SW2-2 SW2-3
1 Closed Closed Closed
10 Open Closed Closed
100 Closed Open Closed
250 Open Open Closed
500 Closed Closed Open
None Closed Open Open
None Open Open Open
Pump/Remote Dispenser Operation
Page 6-6 MDE-4340A Series 9800Q Pumps and Dispensers Installation/Operation Manual · January 2006
Leading zeros are always suppressed in the hundreds and tens positions to the left of the
decimal point. When in standalone mode, positions to the right of the decimal point are
displayed based on the pulse rate selected as shown in the following chart.
Pulse Rate 9800/9840 9850
1:1 XXX. XXXX.
10:1 XXX.X XXXX.X
100:1 XXX.XX XXXX.XX
250:1 XXX.XXX XXXX.XXX
500:1 XXX.XXX
Timeout Switch
When the 9800Q is in standalone mode, it turns off an active hose if it does not detect pulses
for 4 minutes, 15 seconds. This timeout feature can be disabled by setting switch SW2-4 to
OPEN.
Timeout SW2-4
Enabled Closed
Disabled Open
ATC Information Sheet
By activating the magnet located at the opposite side of the totalizer, various items will appear
on the display:
1. Volume Display Displays uncompensated volume 0023.43
2. Probe Temperature Display Displays probe temperature in Celsius only 023.2
3. Flow Reat Display Displays flow rate (in LPM only) 189.2
4. Software Version Display Displays software version number 1.30
5. ATC Status Display Displays ATC Status 842.2
On the status display, the rightmost digit (2) indicates whether or not temperature compression
is enabled, and if so, what product is being dispensed. 0=temperature compensation enabled;
1=product is gasoline and compensation is enabled; 2=product is diesel and compensation is
enabled.
