Figure 17-4
Note: Gray lamps indicate an off or clear condition, while red lamps indicate an on or active condition.
<< Back to Status
MOV Status Detail | MOV Address 001 | [<>]
MOV Tag Name: MOVFU001
Torque 0
Analog #1 0
Analog #2 0
Position 0
STATUS REGISTER
Opened
Closed
Stopped
Opening
Closing
Valve Jammed
Local Mode Selected
Combined Fault
Thermal Overload Fault
Fail De-Energize (UEC-3 ONLY)
Channel A Fault
Channel B Fault
Open Torque Switch Fault
Digital Output
Close Contactor
Open Contactor
AS-1
AS-2
AS-3
AS-4
AR-1, Opt
AR-2, Opt
AR-3, Opt
Digital Inputs 1 (Remote Mode Selected
Thermal Overload Fault
Open Torque Switch
Open Limit Switch
User 0, Terminal-21
User 1, Terminal-10
User 2, Terminal-9
User 3, Terminal-6
User 4, Terminal-7
User 5, Terminal-5
User 6, Terminal-23
User 7, Terminal-24
Digital Inputs 2
Analog In 1 Lost
Analog In 2 Lost
Network A/B Lost
DDC Bd. Present
I/O Opt Board Present
Phase Lost
Network Relay
Close Torque Switch Fault
Manual Operation
Phase Error
FAULT REGISTER
DIGITAL I/O
Phase(s) Missing
Phase Reversed
Network ESD is ON
Local ESD is ON
Unit Reset since last poll
Local Stop Selected
Opening in Local
Closing in Local
Refresh Status
