FCD LMAIM5001-00 DDC-100 Master Station II Installation and Operation Manual 41
Flow Control Division
Limitorque Actuation Systems
Valid Command Register Operations
Values MX-DDC Definition UEC-3-DDC Definition
256 Open Open
512 Stop Stop
768 Close Close
1280 Start / Terminate Network ESD Start / Terminate Network ESD
2304 Engage AS-1 Engage #1 (I/O Module Only)
2560 Engage AS-2 Engage #2 (I/O Module Only)
2816 Engage AS-3 Engage #3
3072 Engage AS-4 Engage #4 (I/O Module Only)
3328 Engage AR-1 Engage #5 (I/O Module Only)
3584 Engage AR-2 Engage #6
4352 Disengage AS-1 Disengage #1 (I/O Module Only)
4608 Disengage AS-2 Disengage #2 (I/O Module Only)
4864 Disengage AS-3 Disengage #3
5120 Disengage AS-4 Disengage #4 (I/O Module Only)
5376 Disengage AR-1 Disengage #5 (I/O Module Only)
5632 Disengage AS-2 Disengage #6
6656 Enables “move-to” for units Enables “move-to” for units
requiring the 2 register writes. requiring the 2 register writes.
19200 + Value Position Value for units capable of Position Valve for units capable of
accepting 1 write “move-to” accepting 1 write “move-to”
Valid Argument Register Operations
Values MX-DDC Definition UEC-3-DDC Definition
0 - 100 Desired Valve Position Desired Valve Position
