15
Logger
The Logger allows the user to monitor the status of the network or communication traffic. The Logger Menu provides
two options: Data Analyzer and Network Status (Figure 15-1).
Figure 15-1: Logger Menu screen
Note: In a Hot Standby configuration, the Standby unit does not report logger functions.
The Data Analyzer screen allows the user to monitor communication traffic (Figure 15-2). Several monitoring options
are available:
Channel A: monitor communication on Channel A port
Channel B: monitor communication on Channel B port
DCS Port: monitor communication on DCS port
MNET Port: monitor communication on Modbus ethernet port
Activity Log Disabled: no logging
Logger
Data Analyzer
Logger Menu ACTIVE
<< Back
