FCD LMAIM5001-00 DDC-100 Master Station II Installation and Operation Manual 45
Flow Control Division
Limitorque Actuation Systems
8
Ethernet Port Configuration
The Master Station includes support for several TCP/IP protocols, including Modbus Ethernet and HTTP (web server).
Each Master Station processing unit must be configured with a unique IP address, mask, gateway, and Hot Standby IP
Address if Hot Standby is installed (Figure 8-1). The Hot Standby IP Address is discussed in detail in Chapter 10.
Note: If Hot Standby is not installed, the Hot Standby IP Address must be 0.0.0.0.
Figure 8-1: The Configure Ethernet Port screen
Touching the “Edit” button for each row will allow the user to edit the octets of the addresses, one octet at a time, from
left to right (Figures 8-2, 8-3, 8-4, 8-5).
Use the “Next” and “Back” buttons on each editing screen to navigate between screens.
Figure 8-2: Edit Octet One screen
<< Back IP Address 1
Current Value:
192
1-255
Valid Range:
1st octet of
IP Address for
this CPU
### ___ ___ ___
192
7 8 9
6 5 4
1 2 3
0 . CLR
DEL
-
E
N
T
Next >>
EDIT EDIT
EDIT EDIT
EDIT EDIT
EDIT EDIT
<< Back Top Screen
IP Address
192 168 0 100
Mask
255 255 255 0
Gateway
192 168 0 1
Hot Standby IP Address
0 0 0 0
Configure Ethernet Port
