32

DDC-100 Master Station II Installation and Operation Manual

FCD LMAIM5001-00

Flow Control Division

Limitorque Actuation Systems

Figure 7-2: The DCS Port Configuration screen

Touching “EDIT” next to “DCS Address,” “RTS ON Delay (ms)” or “RTS OFF Delay (ms)” will allow the

user to enter new values.

Figure 7-3: DCS Port Address screen

DCS Port Address

Current Value:

1

1-247

Valid Range:

Modbus node

address for this

Master Station

for communication

to DCS or PLC.

1

<< Back

7

8

9

6

5

4

1

2

3

0

.

CLR

DEL

-

E

N

T

EDIT

EDIT

EDIT

DCS Port

DCS Address:

RTS ON Delay (ms):

RTS OFF Delay (ms):

0

0

1

HMI State during DCS Comm Traffic

HMI Control On

<< Back

Next >>

EDIT

EDIT

EDIT
