36 DDC-100 Master Station II Installation and Operation Manual FCD LMAIM5001-00
Flow Control Division
Limitorque Actuation Systems
Selecting a register for a specific field unit follows the convention listed below.
Name MX-DDC UEC-3-DDC
Torque Torque (current) Average Torque (Opt)
Volts Actual Volts Not Used
Analog #1 Analog Input (User) Analog Input (User)
Analog #2 Analog Input (User) Analog Input (User)
Position Valve Position (0 - 100%) Valve Position (0 - 100%)
Status Register
Bit 00 Opened Opened
01 Closed Closed
02 Stopped Stopped
03 Opening Opening
04 Closing Closing
05 Valve Jammed Valve Jammed
06 Local Mode Selected Local Mode Selected
07 Combined Fault * Combined Fault *
08 Thermal Overload Fault Thermal Overload Fault
09 Future Use Fail De-Energize
10 Channel A Fault Channel A Fault
11 Channel B Fault Channel B Fault
12 Open Torque Switch Fault Open Torque Switch Faul
13 Close Torque Switch Fault Close Torque Switch Fault
14 Manual Operation Manual Operation
15 Phase Error Phase Error
Fault Register
Bit 00 Not Used Open Verify Fault
01 Not Used Close Verify Fault
02 Not Used Open De-Energize Fault
03 Not Used Close De-Energize Fault
04 Phases Missing Phases Missing
05 Phase Reversed Phase Reversed
06 Not Used Manual Mid to Open
07 Not Used Manual Open to Mid
08 Not Used Manual Mid to Close
09 Not Used Manual Close to Mid
10 Network ESD is ON ** Network ESD is ON**
11 Local ESD is ON Local ESD is ON
12 Unit Reset since last poll Unit Reset since last poll
13 Local Stop Selected Wrong Rotation
14 Opening in Local Opening in Local
15 Closing in Local Closing in Local
